| Size range | 5mm – 110mm (3/16″ – 4 1/3″) |
| Forged Size range | 150mm – 400mm (5/90″ – 16″) |
| Supply conditions | |
| Length | Up to 6.5 meters |
| Tolerances | h8, h9, h10, h11, h12, k12, k13, A-484, EN-10060, DIN-1013 etc. |
| Surface finish | RA upto 0.2 mm (8.7 RMS) |
| Straightness | Up to 0.5 mm per meter TIR |
| Grit polish | K240,K320 or as per customer’s requirement |
| Heat treatment | Soft annealing, solution annealing, oil & water quenching, tempering & normalizing |
| Bars end finish | Chamfered ends, 300, 450 & 600 plain ends without burrs or sharp edges |
| Specifications | As per EN, DIN, JIS, ASTM, BS, ASME, GHOST, AISI/Nace MRO175 |
| Cold drawn, centreless ground, peeled & polished, rough peeled or smooth turned bar | |
| Grade Confirmation through PMI testing with Handheld Spectrometer. | |
| Free from radioactive elements, mercury & lead contamination | |
| Size range | 15mm – 55 mm ( 3/5″ – 2 1/6″) |
| Supply conditions | |
| Length | Up to 6 meters |
| Tolerances | h11, k12, k13 |
| Grit polish | As per customer’s request |
| Heat treatment | Solution annealed, oil & water quenched / tempered, soft annealing |
| Bars end finish | Chamfered ends, plain ends without burrs or sharp edges |
| Specifications | As per EN, DIN, JIS, ASTM, BS, ASME, AISI, etc. |
| Grade confirmation through PMI testing with handheld spectrometer. | |
| Free from radioactive elements, mercury & lead contamination. | |
| Size range | 12.70 mm – 58 mm (1/2″ to 2-2/7″) |
| Supply conditions | |
| Length | Up to 6 meters |
| Tolerances | h11, k12, k13 |
| Grit polish | As per customer’s request |
| Heat treatment | Cold drawn, solution annealed, oil & water quenched / tempered |
| Bars end finish | Chamfered ends, plain ends without burrs or sharp edges |
| Specifications | As per EN, DIN, JIS, ASTM, BS, ASME, AISI, etc. |
| Grade confirmation through PMI testing with handheld spectrometer. | |
| Free from radioactive elements, mercury & lead contamination. | |
